Wholesale factory price T320HVN05.6 AUO 31 lcd screen 32" display panel for outdoor billboard and standing kiosk lcd

T320HVN05.6 is a color active matrix TFT LCD module using amorphous silicon TFT's (Thin Film Transistors) as an active switching devices. This module has a 32 inch diagonally measured active area with FHD resolutions (1920 horizontal by 1080 vertical pixel array).

Each pixel is divided into RED, GREEN, BLUE dots which are arranged in vertical stripe and this open cell can display 16.7M colors. The TFT-LCD panel used for this module is adapted for a low reflection and higher color type.

Features

Super Wide viewing angle

Super High contrast ratio

Super Fast response time

High color saturation

DE(Data Enable ) only mode

LVDS Interface

RoHS compliance

Application

Home Alone Multimedia TFT-LCD TV

Display Terminals for Control System

High Definition TV(FHD TV)

AV application Products

Manufacturer	AUO
Model Name	T320HVN05.6
Screen Size	31.5 inch
Screen Type	a-Si TFT-LCD
Pixel Number	1920(RGB)×1080 (FHD)
Arrangement	RGB Vertical Stripe
Active Area(mm)	698.4 × 392.85 (H×V)
Outline(mm)	708.4 × 405.4 × 1.4 (H×V×D)
Bezel Area(mm)	-
Treatment	Antiglare (Haze 2%), Hard coating (3H)
Luminance	250 cd/m²
Contrast Ratio	4000 : 1 (Typ.) (TM)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Response	6.5 (Typ.)(G to G) ms
Good View at	Symmetry
Work Mode	AMVA3, Normally Black, Transmissive
Glass Thickness	0.50+0.50 mm
Color Depth	16.7M
Backlight	WLED
Used for	TV Sets
Refresh Rate	60Hz
Touchscreen	Without
Signal Type	LVDS (2 ch, 8-bit) , Connector , 51 pins
Voltage Supply	12.0V (Typ.)
Max. Ratings	Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C

Features

Features:

super wide viewing angle
super high contrast ratio
super fast response time
high color saturation
DE(Data Enable) only mode
LVDS Interface
ROHS compliance

Application

Application

Home Alone Multimedia TFT-LCD TV
Display Terminals for Control System
High Definition TV(FHD TV)
AV application Products

General Specification

General Specification：

Brand	AUO
Model	T320HVN05.6 CELL
Diagonal Size	31.5 inch
Type	a-Si TFT-LCD, CELL
Pixel Format	1920(RGB)×1080 [FHD]
Configuration	RGB Vertical Stripe
Active Area	698.4(H)×392.85(V) mm
Outline Dim.	708.4(H)×405.4(V) ×1.4(D) mm
Treatment	Antiglare (Haze 2%), Hard coating (3H)
Luminance	300 cd/m²
Contrast Ratio	4000:1 (Typ.) (TM)
View Direction	Symmetry
Response Time	6.5 (Typ.)(G to G)
Viewing Angle	89/89/89/89 (Typ.)(CR≥10)
Operating Mode	AMVA3, Normally Black, Transmissive
Plate Thickness	0.50+0.50 mm
Transmittance	6.5% (Typ.)(with Polarizer)
Support Color	16.7M
Weight	875g (Typ.)
Designed For	industrial
Frame Rate	60Hz
Touch Panel	Without
Interface Type	51 pins LVDS (2 ch, 8-bit) , Connector
Power Supply	12.0V (Typ.)
Environment	Operating Temperature: 0 ~ 50 °C ; Storage Temperature: -20 ~ 60 °C
