17 inch customized lcd monitor display

Name: 17 inch customized lcd monitor display
Brand: XIANHENG | China LCD display supplier | SHENZHEN LCD module manufacturer
SKU: 17 inch customized lcd monitor display
Availability: InStock
Rating: 5 (1 reviews)

Item No.: 17 inch customized lcd monitor display

17 inch customized lcd monitor built with standard VGA/HDMI/AV/TV input

INQUIRY PDF Format

Description

17 inch customized lcd monitor built with standard VGA/HDMI/AV/TV input

Description

1.Built with Standard VGA input (HDMI/AV/TV is optional)
2.Fully new LED/LCD panel, High contrast and brightness, wide viewing angle, which greatly improve the image layering
3.Built-in Speaker( optional)
4.Built with Standard VESA (75mm or 100mm) Sockets Mounts
5.Sample is avalible
6.Stable Quality

General Specification

Panel size:   17 inch TFT-LCD monitor
Visual size:   337*272mm
Standard Resolution:   1280*1024
Number of Colors:   16.2M
Brightness:   300cd/m2
Response time:   5ms
View angle:   Horizontal: 160°; Vertical: 140°
Contrase ratio:   800:1
Video input format:   (analog) RGB
Connector:   VGA for video signal
Video input connection:   Mini D-Sub 15 Needles VGA
Frequency:   30~80KHz/60~75Hz
Power supply:   External Power Supply: 100 to 240V (DC 12V)
Operation Environment:
Workable Temperature:   -10 to 60°C;
Storage temperature:   -20 to 70°C;
Operate relative humidity:   20% to 80%;
storage relative humidity:   10% to 90%
Net weight:   6.0 Kgs/pcs
Gross weight:   6.5 Kgs/pcs
Power consumption:   Max 30W
Setup (optional):
   1) provide wall brackets for wall-mounting, VESA 75mm&100mm
   2) provide base to support the monitor
OSD control:
   AUTO+, POWER, -, MENU
   brightness, contrast ratio, auto adjustment, phase position, clock, Languages, function, Install, reset
Certificate:   FCC, ROHS
Warranty:   1 year,provide spare parts
Monitor size:   380*308*55mm
(not include base)
Each unit box size:   436*139*429mm
Package size:   4pcs in a carton, carton size:650*450*420mm

17 inch customized lcd monitor display

17 inch customized lcd monitor built with standard VGA/HDMI/AV/TV input
