M195FGE-L20 innolux 19.5 inch screen TFT-LCD display module

M195FGE-L20 innolux 19.5 inch screen TFT-LCD display module

Name: M195FGE-L20 innolux 19.5 inch screen TFT-LCD display module
Brand: XIANHENG | China LCD display supplier | SHENZHEN LCD module manufacturer
SKU: M195FGE-L20
Availability: InStock
Rating: 5 (1 reviews)

Item No.: M195FGE-L20

M195FGE-L20 is a 19.5” TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins 2ch-LVDS interface.

INQUIRY PDF Format

Description

M195FGE-L20 is a 19.5” TFT Liquid Crystal Display module with WLED Backlight unit and 30 pins 2ch-LVDS interface. This module supports 1600 x 900 HD+ mode and can display up to 16.7M colors. The converter module for Backlight is not built in.

General Specification

Panel Brand:    CHIMEI INNOLUX
Panel Size   :    19.5 inch
Panel Model:    M195FGE-L20
Panel Type:    a-Si TFT-LCD , LCM
Pixel Format:    RGB Vertical Stripe
Bezel Opening:    435.3(W)×243.06(H) mm
Surface:    Antiglare (Haze 25%), Hard coating (3H)
Resolution:    1600(RGB)×900 , HD+
Display Area:    432(W)×239.76(H) mm
Outline Size:    452(W)×263(H) ×11(D) mm
Brightness:    250 cd/m² (Typ.)
Viewing Angle:    85/85/80/80 (Typ.)(CR≥10) Left / Right / Up / Down
Best View on:    6 o'clock
Display Colors:    16.7M   72% (CIE1931)
Frequency:    60Hz   [Panelook copyright, copy is strictly prohibited]
Weight:    1.43/1.50Kgs (Typ./Max.)
Contrast Ratio:    1000:1 (Typ.) (TM)
Display Mode:    TN, Normally White, Transmissive
Response Time:    5 (Typ.)(Tr+Td)
Lamp Type:    4 strings WLED , 40K hours , Without Driver
Touch Screen:    Without
Application:    Desktop Monitor
Signal Interface:    LVDS (2 ch, 8-bit) , 30 pins , Connector
Input Voltage:    5.0V (Typ.)
Environment:    Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
