Innolux M270KCJ-L5E is a 27.0 inch diagonal a-Si TFT-LCD display panel product, with an integral WLED backlight system, without backlight driver, without touch screen. It's general features are summarized in the following: 3-side boderless, WLED Backlight , 3-sides borderress.
It features an operating temperature range of 0 ~ 50°C , a storage temperature range of -20 ~ 60°C . Based on its features, we recommend that this model be applied to Desktop Monitor etc.
If you want to embed M270KCJ-L5E LCM in your future product, we strongly recommend that you should contact with Innolux or XIANHENG TECH to learn lateast production and specification detail.
| Manufacturer | Innolux |
| Model Name | M270KCJ-L5E |
| Screen Size | 27.0 inch |
| Screen Type | LCM , a-Si TFT-LCD |
| Pixel Number | 2560(RGB)×1440 (Quad-HD) 108PPI |
| Arrangement | RGB Vertical Stripe |
| Active Area(mm) | 596.736 × 335.664 (H×V) |
| Outline(mm) | - |
| Bezel Area(mm) | - |
| Treatment | Hard coating (3H) |
| Luminance | - |
| Contrast Ratio | 1000 : 1 (Typ.) (TM) |
| Viewing Angle | 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down |
| Response | 14 (Typ.)(G to G) ms |
| Good View at | Symmetry |
| Work Mode | AAS, Normally Black, Transmissive |
| Color Depth | 16.7M 99% sRGB |
| Backlight | WLED , No Driver |
| Mass | - |
| Used for | Desktop Monitor |
| Refresh Rate | 60Hz |
| Touchscreen | Without |
| Signal Type | LVDS (4 ch, 8-bit) , 92 pins Connector |
| Max. Ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
