Large-size Lcd

LC320EUJ-FFE2 LG 31.5" 32 inch lcd display

Item No.: LC320EUJ-FFE2
Top quality LC320EUJ-FFE2 LG 31.5 inch IPS lcd screen with FHD 1920x1080 and full view angle widely used around the world.
Description

Top quality LC320EUJ-FFE2 LG 31.5 inch IPS lcd screen with FHD 1920x1080 and full view angle widely used around the world.

The LC320EUJ is a Color Active Matrix Liquid Crystal Display with an integral the Source PCB and Gate implanted on Panel (GIP). The matrix employs a-Si Thin Film Transistor as the active element. It is a transmissive type display operating inthenormally black mode. Ithas a 31.55inchdiagonally measured active display area with WUXGA resolution (1080 vertical by1920 horizontal pixel array). Each pixel is divided into Red, Green and Blue sub-pixels ordots which are arranged in vertical stripes. Gray scale orthe luminance ofthe sub-pixel color is determined with a 8-bit gray scale signal for each dot. Therefore, it can present a palette of more than 16.7Milion colors.  It is intended tosupport LCD TV, PCTV where high brightness, super wide viewing angle, high color gamut, high color depth and fast response time are important.

 General Specification
Panel Brand    LG
DisplayPanel Model    LC320EUJ-FFE2
Panel Size    31.5 inch
Panel Type    a-Si TFT-LCD, CELL
Resolution    1920(RGB)×1080 , FHD
Pixel Format    RGB Vertical Stripe
Display Area    698.4(W)×392.85(H) mm
Bezel Opening    -
Outline Size    714(W)×411(H) ×1.4(D) mm
Surface    Antiglare (Haze 1%), Hard coating (3H)
Brightness    0 cd/m²
Contrast Ratio    1400:1 (Typ.) (TM)
Viewing Angle    89/89/89/89 (Min.)(CR≥10) Left / Right / Up / Down
Display Mode    IPS, Normally Black, Transmissive
Display Colors    16.7M
Lamp Type    No B/L
Frequency    60Hz
Touch Screen    Without
Panel Weight    840/880g (Typ./Max.)
Application    TV Sets
Signal Interface    LVDS (2 ch, 8-bit) , 51 pins , Connector
Input Voltage    12.0V (Typ.)
Environment    Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
