S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module

No.S290AJ1-LE2
The S290AJ1-LE2 Rev.C1 is a 28.6-inch diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, With LED Driver, without a touch screen.
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module
  • S290AJ1-LE2 innolux 28.6 inch screen TFT LCD display module

Description

The S290AJ1-LE2 Rev.C1 is a 28.6-inch diagonal a-Si TFT-LCD display panel product from Innolux Corporation (hereafter called Innolux), with an integral WLED backlight system, With LED Driver, without a touch screen.
It features an operating temperature range of 0 ~ 50°C and a storage temperature range of -20 ~ 60°C. Its general features are summarized in the following: sRGB, Landscape / Portrait, WLED Backlight, With LED Driver, Bar Display, Matte, 1/2 cut of 31.5", 50/60Hz. Based on its features, XIANHENG recommends that this model be applied to Digital Signage, Stretched Bar LCD, etc.
If you want to embed S290AJ1-LE2 Rev.C1 LCM in your future product, XIANHENG strongly recommends that you should contact Innolux or XIANHENG TECH to learn the latest production and specification detail.

General Specification
Brand Innolux
Model P/N S290AJ1-LE2 Rev.C1
Diagonal Size 28.6"  (1/2 cut of 32.0")
Panel Type a-Si TFT-LCD, LCM
Resolution 1920(RGB)×540  69PPI
Pixel Format RGB Vertical Stripe
Active Area 698.4(W)×196.425(H) mm
Bezel Opening 702.4(W)×200.4(H) mm
Outline Size 720.8(W)×226.3(H) ×26.8(D) mm
Surface Antiglare (Haze 2.4%), Hard coating (3H)
Brightness 500 cd/m² (Typ.)
Contrast Ratio 4500:1 (Typ.) (TM)
Viewing Angle 89/89/89/89 (Typ.)(CR≥10) Left / Right / Up / Down
Display Mode Super MVA, Normally Black, Transmissive
Best View on Symmetry
Response Time 10 (Typ.)(G to G)
Display Colors 16.7M   72% NTSC
Lamp Type WLED , 30K hours , With LED Driver
Frequency 60Hz
Touch Screen Without
Panel Weight 2.49Kgs (Typ.)
Application Digital Signage Stretched Bar LCD
Signal Interface LVDS (2 ch, 8-bit) , 51 pins Connector
Input Voltage 12.0V (Typ.)
Environment Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C
